Description
SNTS303 fiber access termination box is able to hold up to 16 subscribers.It is used as a termination point for the feeder cable to connect with drop cable in FTTx network system.It integrates fiber splicing,splitting,distribution,storage and cable connection in one solid protection box.
PP material used ensures the body strong and light.
Water-proof design for outdoor uses.
Easy installations: Ready for wall mount - installation kits provided.
Adapter slots used - No screws and tools needed for installing adapters.
Ready for splitters: designed space for adding splitters.
Space saving! Double-layer design for easier installation and maintenances:
Lower layer for splitters and over length fiber storage.
Upper layer for splicing, cross-connecting and fiber distribution.
Cable fixing units provided for fixing the outdoor optical cable.
Protection Level: IP66.
Accommodates both cable glands as well as tie-wraps
Lock provided for extra security
Feature
1.Water-proof design with IP-66 Protection level.
2.Integrated with splice cassette and cable management rods.
3.Manage fibers in a reasonable fiber radius condition.
4.Easy to maintain and extend the capacity.
5.Fiber bend radius control more than 40mm.
6.Suitable for the fusion splice or mechanical splice.
7.2 pcs of 1*8 Splitter can be installed as an option.
8.Efficient cable management.16 ports cable entrance for drop cable
Application
1.Optical LAN & WAN & CATV
2.FTTH project & FTTX Deployments
3.Broadband High-bit rate data transmission
4.Active device terminations
5.Testing instruments
6.Optical fiber communication networks
7.PON Networks
8.Optical Signal Distribution
SNTS303 Fiber Optical Splice Box | |
Material | PP+Glass Fiber |
Size | 380*245*130mm |
Cable Ports | 1pc un-cut cable port, 2pcs output cable ports, 16pcs drop cable ports |
Max Capacity | 96FO |
Splice Tray | 2 pcs 100%PC Material |
Weight | 4.5~5KG |
Accessories | Protecting Sleeves, labelling paper, insulation tape, abrasive paper, wall-mount kits, sealing tape, nylon tie, earthing wire, plastic wrench |
Sealing Way | Silicon Rubbersealing Ring |
Installation Way | Aerial, wall or pole-Mounting |
