FTTH Fiber Optic 40G Trunk Cable MPO MTP Connector Jumper
Description
Fiber Patch Cord is a fiber optic cable capped at either end with connectors that allow it to be rapidly and conveniently connected to CATV, an optical switch, or other telecommunication equipment. Having a thick layer of protection, it is used to connect the optical transmitter, receiver, and the terminal box. This is known as "interconnect-style cabling"
Product Features:
Low Insertion loss
Low PDL
Excellent channel-to-channel uniformity
High return loss and Good repeatability
Wide wavelength range
Applications:
LAN, WAN and Metro Networks
FTTH project & FTTX Deployments
CATV System
GPON, EPON
Fiber Optic Test Equipment
Data-base Transmit Broadband Net
Compliance:
Telcordia GR-1209-CORE-2001
Telcordia GR-1221-CORE-1999
YD-T2000.1-2009
RoHS
1. Are you a manufacturer or trade company?
A: We are the FTTH manufacturer with nearly 20 years' history. Now our factory is not only in Ningbo, but also have a production center in Jilin, covering an area nearly 23000 Sqm, owning 1500 workers.
2.Can I have a sample order for this product?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
4. How about your price?
A: We are supplying products with very competitive price based on good performance.
5.Do you offer OEM Service ?
A: We accept OEM, ODM. The cable size and material are customized. Our own logo and own design are welcome. We will produce according to your requirment and description
Description
Fiber Patch Cord is a fiber optic cable capped at either end with connectors that allow it to be rapidly and conveniently connected to CATV, an optical switch, or other telecommunication equipment. Having a thick layer of protection, it is used to connect the optical transmitter, receiver, and the terminal box. This is known as "interconnect-style cabling"
Product Features:
Low Insertion loss
Low PDL
Excellent channel-to-channel uniformity
High return loss and Good repeatability
Wide wavelength range
Applications:
LAN, WAN and Metro Networks
FTTH project & FTTX Deployments
CATV System
GPON, EPON
Fiber Optic Test Equipment
Data-base Transmit Broadband Net
Compliance:
Telcordia GR-1209-CORE-2001
Telcordia GR-1221-CORE-1999
YD-T2000.1-2009
RoHS
| Model | SM | MM |
| Connector Fiber Count | 8, 12, 24 core | |
| Polish | PC, APC | |
| Housing Color | Standard (green), | Standard(Beige) |
| Elite (Yellow) | Elite(Auqa) | |
| Insertion Loss Standard type | less than 0.7dB | Less than 0.5dB |
| Insertion loss Elite type | Less than 0.35dB | Less than 0.3dB |
| Return Loss | PC >50dB, APC>60dB | >30dB |
| Durability (500 matings) | less than 0.2dB | |
| Test Eavelength | 1310/1550nm | 850/1300nm |
| Fiber Type | OS2, OM1, OM2, OM3, OM4 |
| Fiber Count | 8, 12, 24, 48, 72, 96, 144 cores |
| Cable Diameter | 3.0mm 5.5mm or customized |
| Jacket Color | Yeloow, Orange, Aqua, Purple |
| Jacket Material | OFNR, OFNP, PVC, LSZH |
| Tensile Strength | 500N |
| Operating Temperature | -20 to 70 ºC |
| Storage Temperature | -40 to 75ºC |
1. Are you a manufacturer or trade company?
A: We are the FTTH manufacturer with nearly 20 years' history. Now our factory is not only in Ningbo, but also have a production center in Jilin, covering an area nearly 23000 Sqm, owning 1500 workers.
2.Can I have a sample order for this product?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
3. What about the lead time?
A: Sample needs 1-2 days, mass production time needs 1-2 weeks
4. How about your price?
A: We are supplying products with very competitive price based on good performance.
5.Do you offer OEM Service ?
A: We accept OEM, ODM. The cable size and material are customized. Our own logo and own design are welcome. We will produce according to your requirment and description
6. Do you offer guarantee for the products?
A: Yes, we offer 1-2 years warranty to our formal products.
